GA/T42.2 Flame Retardant Wood Combustion Test Device Fire Tube Method Fire Testing Equipment

Flame Retardant Wood Combustion Test Device





Scope of application:
Mainly applicable for testing the combustion quality loss rate and flame burning time of indoor decoration wood panels and wooden products (d ≤ 20mm) that have been treated with flame retardant impregnation under specified combustion conditions.

Compliant with standards:
Developed in accordance with the technical parameters specified in GA/T42.2-92.



Main parameters:
Environmental temperature: -5 ℃ -30 ℃;
Environmental humidity: ≤ 70% Operating voltage: AC220V ± 10V;
Microcomputer control; Automatic ignition and timing;
Real time temperature display; Data printing.
Gas source: natural gas, liquefied petroleum gas, purity 95% (to be provided by the user);
Timing accuracy: 0.1s;
Temperature error: 180 ± 100C;
Dimensions approximately: 680mm × 320mm × 1500mm;
Test piece size mm: 1016 ± 1 × 19 ± 1 × 10 ± 1 Quantity: 3 pieces. When the length of the test piece is less than the requirement, it can be connected by two or more short test pieces with iron wire or nails, with a total length of 1016mm ± 1m
Equipment weight: 25Kg
